VESSEL Static Eraser F120R-E 621651

Benefits

• Newly developped piezoelectric transformer makes the slim and compact model.
• Butterfly louvers for changing the wind directions.
• Fan speed can be adjusted in three steps.
• Improvement in maintenance by easy replaceable electrode needle unit.
• Equipped with terminals for alarm signal output, convenient for incorporation into equipment.
• F120S-E is a silent type with mild airflow.

Features

• Ionizing method : Piezoelectric high frequency
• Dacay time: Within 2.5 Sec
• Ion balance : Within +/-10 V

Specifications

• Model : F120S-E
• Body Size: 198 MMx162 MMx69.5 MM
• Weight: 900 Gr
• Applied voltage: AC10 KV(p-p)
• Power supply: DC24 V +/-5%
• Current consumption max. 500 mA
• Noise level: 51 dBA
• Fan speed max: 2.21 M3/Min
• EDP No.: 621646

Technical Spec

• Netto Weight: 0.900 KG
• Height Demension: 10.000
• Length Demension: 22.000
• Width Demension: 18.000
• Type: FAN IONIZER
• Dimension uom: 22.000
