SOYER Welding Pistol for BMK10 PH-3 PH-3N

Welding Pistol for BMK10 PH-3 PH-3N

Benefits

• Optimum protection against welding spatter, dirt and other contamination
• Very precise stud positioning owing to motional sequence which are free from backlash
• Long service life and long term quality owing to wear free guide bush with ball bearing and specially surface hardened and ground guide piston
• Suitable for application in complicated, narrow location and areas of difficult access

Features

• Ergonomically and slim design
• Low weight
• Fatigue-proof welding of studs and pins with a maximum diameter of up to 12mm
• Multifunctional application for drawn arc and short cycle drawn arc stud welding

Specifications

• Weight : 1 kg
• Welding Range : Studs and Pin M3-M12 or 2-12 mm diameter
• Materials : Stainless steel, and heat-resistant steel < li> Welding and Control Cable : 3m
• Welding Sequence : up to 20 studs/min, depending on dimensions

Technical Spec

• Netto Weight 1.000 KG
• Unit Dimension 150 X 50 X 50 MM
• Height Dimension 50.000
• Length Dimension 150.000
• Width Dimension 50.000
• Type Stud Welding
• Dimension uom 150.000
