MITUTOYO Od Micrometer 75-100/0.01MM 102-304

Features

• Vernier scale in metric units for taking precise outside diameter(OD) measurements
• Ratchet-stop mechanism helps provide uniformpressure for precise, repeatable measurements
• Heat-insulat ed frameto help reduce temperature-related expansion or contraction
• Satinchrome finish on thimble and sleeve helps resist rust and reduceglare
• Carbide facing on spindle and anvil provides wear resistance

Specifications

• Gradient Spacing : 0.01 MM
• Maximum Measurement:75-100mm Measurement Accuracy : +/-0.003mm
• Part Number :102-304
• Range : 75-100mm
• Resolution : 0.01mm
• SizeName : 75-100mm

Technical Spec

• Netto Weight: 0.490 KG
• Unit Demension: 271 X 167 X 42 MM
• Height Demension: 4.200
• Length Demension: 27.100
• Width Demension: 16.700
• Material: Carbide
• Type: Outside Micrometer
• Dimension uom: 27.100
