Pferd Grinding Wheel E180-4.1SGINOX 475287
Pferd Grinding Wheel E180-4.1SGINOX 475287
Merek:
Pferd
Model:
475287
Deskripsi Produk

Pferd Grinding Wheel E180-4.1SGINOX 475287

Benefits

  • Professional tool in hardness grade N-INOX.
  • PFERD product type characterized by exceptionally aggressive grinding performance and very long tool life.
  • Provides outstanding shape stability in pipeline applications.
  • Abrasive: Special aluminium oxide A Manufactured without addition of ferrous, sulphurous or chlorinated fillers.
  • Workpiece materials: Stainless steel (INOX)
  • Application: Surface grinding, work on weld seams, chamfering, deburring, fillet weld grinding, grouting
  • Recommen dation for use: Provides optimum grinding results on highpowered angle grinders.

Features

  • EN Designation: Designation and shape of the tool

  • 1 = Grinding wheel, fl at type
  • 6 = Cylindrical cup wheels
  • 11 = C up wheel, tapered type
  • 27 = Grinding wheel, depressed centre type
  • 29 = Semi-fl exible grinding wheel, depressed centre type

    Abrasive

  • A = Aluminium oxide
  • AC = Aluminium oxide/silicon carbide
  • C = Silicon carbide
  • C O = Ceramic grit
  • Z = Zirconia alumina
  • ZA = Zirconia alumina/al uminium oxide

    Grit size

  • Grit size acc. to ISO 8486

    Hardness grade (wheel properties)

  • Very soft: K, H
  • Soft: L, M, N
  • Medium-Hard: P, O, Q
  • Hard: R, S
  • Very hard: T

    Bond

  • BF = Resinoi d bond, fi bre-reinforced, woven or non-woven
  • B = Resin oid bond and other duroplastic bonds

    Max. operating speed in (m/s)

Specifications

  • Diameter: 178 mm
  • Thickness: 4.1 mm
  • Hole: 22.23 mm
  • Max speed: 8600 Rpm
  • EN designation:27 A 30 N BF 80
  • Grit size: 30

Technical Specifications

  • Netto Weight : 0.27 KG
  • Unit Demension : 17.8 X 0.5 X 0.5 CM
  • Height Demension : 0.5 CM
  • Length Demension : 17.8 CM
  • Width Demension : 0.5 CM
  • Type : SG Elastic
  • Dimension uom : 17.8
Rp 164.404
(exc. PPN)
Rp 182.488
(inc. PPN)
Lead time diperlukan 90 hari kerja.
Barang akan siap dikirim dalam waktu tenggang yang ditentukan.
