Feeler Cnc Machine Vmc VMP-23A With Fanuc
Brand: | FEELER |
Model: | Vmc VMP-23A |
Product Description
FEELER Cnc Machine Vmc VMP-23A With Fanuc
CNC MACHINE VMC VMP-23A WITH FANUC
Benefits
- FEELER is one of the leading machine tools manufacturers in Taiwan
- Machine design with quality, reliability, User friendly and safety
- Stable quality products for Industrial grade machining center
- International warranty for controller
Features
- Rugged Construction assure rigidity and balance
- Heavy duty linearguide
- High precision ballscrews and bearing
- Efficient Auto Tool Changer Arm type
- High end Servo System directly connect to the ballscrew
- Fully Enclosed coverguard
- Chip conveyor and bucket
- Spindle oil cooler
- Rigid taping
- Automatic lubrication
- Coolant system
Specifications
- X x Y x Z Travels : 580 x 420 x 510 mm
- Table surface to spindle : 80 – 590 mm
- Table working area : 420 x 650 mm
- Max Load 300 kg
- Spindle speed : 10000 Rpm
- Spindle taper : BT40
- Tool storage capacity : 20 tools
- Spindle motor power : 11 / 7.5 kW
- Controller FANUC
Technical Spec
- Netto Weight 3000.000 KG
- Unit Dimension 190X225.5X237CM
- Height Dimension 257.000
- Length Dimension 210.000
- Width Dimension 245.500
- Type Vertical Machining Center
- Dimension uom 210.000
US $ 132,575.96
Lead time of 90 working days required.
Item will be ready to dispatch within the lead time specified.
