BRADY Vinyl BMP71 Permasleeve BM71-125-175-342

Features

• 3:1 heat shrinkable sleeve fits snuggly around wire for identification and protection.
• Fade resistant and flame retardant. Meets the following material and physical property specifications.
• SAE-AMS-DTL-23053/5C (Class 1)
• SAE-AS-81531
• MIL-STD-202 RoHS Compliant
• UL Recognized
• Tested per: ASTM E162 and A STM E662

Specifications

• Application(s): Panel Identification, Wire & Cable Marking
• Agency Approval(s)/Compliance: MIL-STD-202, SAE-AS-81531, SAE-DTL-23053/5 Class 1, UL Recognized
• Size: 1.765INCW x 0.235IN CH (44.830 mm W x 5.970 mm H)
• Range of Wire Diameter: 0.046INC- 0.110INC(1.17 mm - 2.79 mm)
• Max Characters Per Line For Font #2 : 41
• Max Lines of Text For Font #2: 1
• Label Type/Style: Sleeve
• Color: White
• Wire Gauge: 22 to 16
• Finis h: Matte
• Qty Per Row: 1
• Material Type: Polyolefin < li> Material Description: PermaSleeve Heat-Shrink Polyolefin
• Bra dy Material #: B-342
• Recommended Ribbon Series: M71-R4300 BK < li> Printer Compatibility: BMP71
• Special Properties: Heat-shr inkable, Self-Extinguishing
• RoHS Compatibility: Pass 2011/ 65/EU
• QTY/UOM: 1,000/Roll

Technical Spec

• Netto Weight: 2.150 KG
• Unit Demension: 15 X 6 X 6 CM
• Height Demension: 6.000
• Length Demension: 15.000
• Width Demension: 6.000
• Material: Vinyl
• Color: White
• Type: Wire Marking Sleeves
• Content Length: 1000 /Roll
• Temperature Ranger: -40 to 175 Deg. F
