ASCO RED HAT 12VDC Solenoid Valve VALVE CATALOG NO: 8210G034 :

Product Description

Normally Closed Solenoid Valve

This is a normally closed solenoid valve from ASCO. The valve is rated for both indoor and outdoor use. Valve handles liquid, corrosive, and air/inert gas service. Applications include car washes, air compressors, pumps, laundry equipment, and industrial water control.

Specifications:

• Item: Solenoid Valve

• Solenoid: Valve Product Group

• Solenoid: Valve

• Valve Ways and Positions: 2-Way/2-Position

• Valve: Configuration

• Normally: Closed

• Media: Valves, Air, Inert Gases, Light Oil, Water

• Pipe Size - Valves: 1 in

• Min. Operating Pressure Differential: 0 PSI

• Max. Operating Pressure Differential Air/Inert Gas: 150 PSI

• Max. Operating Pressure Differential Light Oil: 125 PSI

• Max. Operating Pressure Differential Water: 125 PSI

• Environmental Rating - Valves: Indoor, Outdoor

• Voltage: 24V AC

• Coefficient of Volume: 13

• Body Material - Valves: Brass

• Coil Insulation Class: F

• Seal Material - Valves: NBR

• Orifice Diameter: 1 in

• NEMA Rating: 1, 2, 3, 3S, 4, 4X

• IP Rating: 66

• Max. Fluid Temperature: 180 Degrees F

• Hz: 60

• Watts: 16.1 W

• Coil Enclosure: Watertight No Junction Box

• Electrical Connections: 1/2 in Conduit w/18 in Leads

• Overall Length: 3 3/4 in

• Overall Width: 3 1/4 in

• Overall Height: 5 1/8 in

• Center Line Pipe Center Size: 4 5/16 in

• Application: Air Compressors, Car Wash, Industrial Water Control, Laundry Equipment, Pumps

Features :

• Wide range of pressure ratings, sizes, and resilient materials provide long service life and low internal leakage
• High Flow Valves for liquid, corrosive, and air/inert gas service
• Industrial applications include: Car wash, Laundry equipment, Air compressors, Industrial water control, Pumps

Solenoid Enclosures :

• Standard: RedHat II - Watertight, Types 1, 2, 3, 3S, 4, and 4X; RedHat - Type I.
• Optional: RedHat II - Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9; Red-Hat - Explosionproof and Watertight, Types 3, 4, 4X, 7, and 9. (To order, add prefix "EF" to catalog number, except Catalog Numbers 8210B057, 8210B058, and 8210B059, which are not available with Explosionproof enclosures.) See Optional Features Section for other available options.
