PermaSleeve® PS Heat-Shrink Polyolefin (B-342) wire marking sleeves combine speed, ease of use, and permanence to create long-lasting, high quality identification.
- 3:1 heat shrinkable sleeve fit snugly around wires for maximum insulation protection and permanent identification
- Fade-resistant and smudge-proof for superior aesthetic appearance
- Cold resistant and flame-retardant with an operating temperature of -67°F to 275°F (-55°C to 135°C)
- Meets SAE-AMS-DTL-23053/5C (Class 1), SAE-AS-81531, MIL-STD-202;RoHS Compliant;and UL Recognized
- A ribbon is required to print this material. Use Part Number M61-R4310 for the BMP®61 Label Printer / BradyPrinter M611 Mobile Label Printer or M71-R4300 for the BMP®71 Label Printer
Specifications:
- Dimensions 0.645 in H x 1.75 in W
- Height : 0.645 in
- Width : 1.75 in
- Roll Width : 1.75 in
- Sleeve Size : 0.375 in Dia x 1.75 in W
- Sleeve Width : 1.75 in
- Vertical Repeat : 1 in
- Recovered Diameter : 0.125 in
- Recovered Wall Thickness : 0.025 in
- Web Width : 2.25 in
- Diameter as Supplied : 0.375 in
